Tabellout

Download PDF data sheet
Photo coming soon

Particulars

Owner: ANBT (Agence Nationale des Barrages et Transfert)

Designer: Tractebel Engineering

Contractor: Razel-Bec, CMC Ravenna J.V.

Statistics

Type: Arch-Gravity

Purpose(s): Irrigation / Water Supply

Reservoir capacity: 294 m3x106

Height: 121 metres

Length: 366 metres

Volume of RCC: 975 m3x103

Total volume: unknown

Construction Dates

Start of Project: 03/10 (March 2010)

Start of RCC: 03/13 (March 2013)

End of RCC: 08/15 (August 2015)

End of Project: 12/15 (December 2015)

Country: Algeria

River: Djendjen

DMS Co-ordinates: unknown

DD Co-ordinates: unknown

Facings

Upstream

SlopeType
 Reinforced conventional concrete cast after RCC placement

Downstream

SlopeType
 Reinforced conventional concrete cast after RCC placement

Spillway

SlopeType
 Reinforced conventional concrete cast after RCC placement  [stepped face]

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
85
Pozzolan (kg/m3)Pozzolan Type
45
