Bailianya

Download PDF data sheet
Bailianya completed
Bailianya completed

Particulars

Owner: Anhui Water Resources Development Co. Ltd.

Designer: Institute of Investigation, Design and Research for Hydropower Projects, Anhui Province

Contractor: Fujian (Minjiang) Construction Bureau

Statistics

Type: Thin Arch

Purpose(s): Flood Control / Hydropower / Irrigation / Water Supply

Reservoir capacity: 453 m3x106

Height: 105 metres

Length: 422 metres

Volume of RCC: 485 m3x103

Total volume: 560 m3x103

Construction Dates

Start of Project: /05 ( 2005)

Start of RCC: /06 ( 2006)

End of RCC: /07 ( 2007)

End of Project: 04/09 (April 2009)

Country: China

River: Dongpi

DMS Co-ordinates: unknown

DD Co-ordinates: unknown

Facings

Upstream

SlopeType
VerticalTraditional concrete against formwork

Downstream

SlopeType
0.335Traditional concrete against formwork

Spillway

SlopeType
0.335Traditional concrete against formwork

Placement

Layers (mm)Lifts (mm)
3003000

Cementitious material

Cement (kg/m3)
72
56
Pozzolan (kg/m3)Pozzolan Type
108Low-lime flyash (ASTM Class F)
84
