Bertarello

Download PDF data sheet
Photo coming soon

Particulars

Owner: CORSAN (Companhia Riograndense de Saneamento)

Designer: Magna Engenharia Ltda

Contractor: Saneasul SA

Statistics

Type: Gravity

Purpose(s): Water Supply

Reservoir capacity: 6 m3x106

Height: 29 metres

Length: 219 metres

Volume of RCC: 80 m3x103

Total volume: 115 m3x103

Construction Dates

Start of Project: /98 ( 1998)

Start of RCC: 08/98 (August 1998)

End of RCC: 07/99 (July 1999)

End of Project: /00 ( 2000)

Country: Brazil

River: Arroio Burati

DMS Co-ordinates: unknown

DD Co-ordinates: 0.000016, 0.000606

Facings

Upstream

SlopeType
VerticalReinforced concrete cast against precast units or slip-formed facing elements

Downstream

SlopeType
 Reinforced conventional concrete cast after RCC placement  [stepped face]

Spillway

SlopeType
 Reinforced conventional concrete cast after RCC placement  [stepped face]

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
72
Pozzolan (kg/m3)Pozzolan Type
18Natural pozzolan (ASTM Class N)
