Bouhouda

Download PDF data sheet
Bouhouda completed
Bouhouda completed

Particulars

Owner: Direction des Arrenagements Hydrauliques

Designer: Team Maroc

Contractor: Direction des Aménagements Hydrauliques

Statistics

Type: Gravity

Purpose(s): Irrigation / Water Supply

Reservoir capacity: 56 m3x106

Height: 55 metres

Length: 174 metres

Volume of RCC: 165 m3x103

Total volume: 186 m3x103

Construction Dates

Start of Project: 05/95 (May 1995)

Start of RCC: 04/96 (April 1996)

End of RCC: 05/98 (May 1998)

End of Project: 09/98 (September 1998)

Country: Morocco

River: Sraa

DMS Co-ordinates: 34˚36'37.74"N, 4˚34'25.78"W

DD Co-ordinates: 34.610481, -4.573828

Facings

Upstream

SlopeType
0.20Traditional concrete against precast concrete panels

Downstream

SlopeType
0.80Traditional concrete against formwork  [stepped face]

Spillway

SlopeType
0.80Traditional concrete against formwork  [stepped face]

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
100
120
Pozzolan (kg/m3)Pozzolan Type
0Natural pozzolan (ASTM Class N)
0
