Hunting Run

Download PDF data sheet
Hunting Run completed
Hunting Run completed

Particulars

Owner: Spotsylvania County

Designer: Gannett Fleming, Inc.

Contractor: ASI-RCC, Inc.

Statistics

Type: Gravity

Purpose(s): Water Supply

Reservoir capacity: 2 m3x106

Height: 36 metres

Length: 720 metres

Volume of RCC: 115 m3x103

Total volume: 128 m3x103

Construction Dates

Start of Project: 05/00 (May 2000)

Start of RCC: 02/01 (February 2001)

End of RCC: 01/02 (January 2002)

End of Project: 08/02 (August 2002)

Country: USA

River: Hunting Run

DMS Co-ordinates: 38˚21'8.09"N, 77˚38'18.33"W

DD Co-ordinates: 38.352245, -77.638428

Facings

Upstream

SlopeType
VerticalRCC against precast concrete panels with geomembrane

Downstream

SlopeType
 Unformed face of RCC

Spillway

SlopeType
 Unformed face of RCC

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
74
Pozzolan (kg/m3)Pozzolan Type
37Low-lime flyash (ASTM Class F)
