Ouldjet Mellegue

Download PDF data sheet
Photo coming soon

Particulars

Owner: ANBT (Agence Nationale des Barrages et Transfert)

Designer: ENB

Contractor: Cosider TP

Statistics

Type: Gravity

Purpose(s): Irrigation / Water Supply

Reservoir capacity: 155 m3x106

Height: 51 metres

Length: 900 metres

Volume of RCC: 245 m3x103

Total volume: 320 m3x103

Construction Dates

Start of Project: 10/11 (October 2011)

Start of RCC: /13 ( 2013)

End of RCC: /17 ( 2017)

End of Project: /18 ( 2018)

Country: Algeria

River: Mellegue

DMS Co-ordinates: 35˚58'36.09"N, 08˚01'41.76"E

DD Co-ordinates: 35.976692, 8.028267

Facings

Upstream

SlopeType
VerticalReinforced conventional concrete cast before RCC placement

Downstream

SlopeType
0.90RCC against precast concrete blocks

Spillway

SlopeType
0.90Reinforced conventional concrete cast after RCC placement

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
110
Pozzolan (kg/m3)Pozzolan Type
0No pozzolan used  -
