Sfeissif

Download PDF data sheet
Sfeissif completed
Sfeissif completed

Particulars

Owner: unknown

Designer: unknown

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): unknown

Reservoir capacity: 20 m3x106

Height: 28 metres

Length: unknown

Volume of RCC: unknown

Total volume: unknown

Construction Dates

Start of Project: /08 ( 2008)

Start of RCC: /09 ( 2009)

End of RCC: /10 ( 2010)

End of Project: /11 ( 2011)

Country: Morocco

River: Safsaf

DMS Co-ordinates: 32˚20'9.8"N, 1˚20'45.3"W

DD Co-ordinates: 32.336056, -1.345917

Facings

Upstream

SlopeType
VerticalTraditional concrete against precast concrete panels

Downstream

SlopeType
0.85Traditional concrete against formwork  [stepped face]

Spillway

SlopeType
0.85Traditional concrete against formwork  [stepped face]

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
120
Pozzolan (kg/m3)Pozzolan Type
0No pozzolan used  -
