Shankouyan
Download PDF data sheet
Shankouyan completed
Particulars
Owner: Shankouyan Hydro Project Development Co.
Designer: Jiangxi Institute of Investigation and Design of Water Conservancy and Hydropower
Contractor: unknown
Statistics
Type: Thin Arch
Purpose(s): Hydropower
Reservoir capacity: 105 m3x106
Height: 99 metres
Length: 268 metres
Volume of RCC: unknown
Total volume: 272 m3x103
Construction Dates
Start of Project: 11/07 (November 2007)
Start of RCC: —/09 (— 2009)
End of RCC: —/12 (— 2012)
End of Project: —/13 (— 2013)
Country: China
River: Yuanhe
DMS Co-ordinates: 27˚35'8.70"N, 114˚0'40.4"E
DD Co-ordinates: 27.585751, 114.011223
Facings
Upstream
| Slope | Type |
|---|---|
Downstream
| Slope | Type |
|---|---|
Spillway
| Slope | Type |
|---|---|
Placement
| Layers (mm) | Lifts (mm) |
|---|---|
Cementitious material
| Cement (kg/m3) |
|---|
| Pozzolan (kg/m3) | Pozzolan Type |
|---|---|
