Dam Search Results

There are 6 dams matching your search
Click to show/hide your search criteria

Volume: Volume of RCC: 200 m³x10³

Please note: only dams ≥ 15m which have been completed, are under construction, or due to begin RCC placement in the current year are included in the table below.

Results are sorted in the following order: Finish of RCC, Start of RCC, Finish of Project, Start of Project, Height and alphabetical by Dam Name.

← Scroll the table horizontally to view its entire width →

Name	Country	Owner	Purpose	River	Reservoir capacity (m³x10⁶)	Construction dates				Dimensions		Volume		Facings						Placement		Cementitious material
						Start		Finish		Height	Length	RCC	Total	Upstream		Downstream		Spillway		Layers	Lifts	Cement	Pozzolan
						Project	RCC	RCC	Project	(m)	(m)	(m³x10³)	(m³x10³)	Slope	Type	Slope	Type	Slope	Type	(m)	(m)	(kg/m³)	(kg/m³)
Cenza	Spain	Iberdrola, S.A.	H	Cenza	43	01/92	03/93	08/93	12/93	49	609	200	225	V	(3)	0.122 0.75	(3)* (3)*	0.75	(3)*	300	300	70	130	(F)
Fundão	Brazil	ELEJOR - Centrais Elétricas do Rio Jordão	H	Jordao	34	- /04	- /05	- /06	- /07	43	445	200	220							300	300	64	16	(N)
Castro Alves	Brazil	CERAM (Companhia Energética Rio das Antas)	H	Das Antas	127	- /05	- /06	- /07	- /08	48		200										60	15	(N)
Vaca	Belize	Belize Electric Company Ltd (BECOL) and A. Fortis Company, Canada	H	Marcal	12	02/07	02/08	10/09	12/11	70	245	200	220	0.20	(1)	0.75	(3')*	0.75	(12)	300	3600	94	31	(F)
Batu Hampar	Malaysia	Jabatan Bekalan Air Negeri Sembilan	W	Batu Hampar	3	11/07	10/09	04/10	05/10	75	236	200	203		(3')		(10)		(10)	300	300	65	120	(F)
Boqaata	Lebanon	Ministry of Energy and Water	W		6	07/12	04/15	12/16	- /17	72	222	200	255	V 0.80	(12)	0.80	(3')*	0.80	(3')*	300	300	90	0	(-) -

← Scroll the table horizontally to view its entire width →

Search again

Please note: only dams ≥ 15m which have been completed, are under construction, or due to begin RCC placement in the current year are included in the list below.

Results are sorted in the following order: Finish of RCC, Start of RCC, Finish of Project, Start of Project, Height and alphabetical by Dam Name.

Cenza

Full Dam Information

Details

Country: Spain

Owner: Iberdrola, S.A.

Type: Gravity

Purpose(s): Hydropower

River: Cenza

Reservoir capacity: 43 m³x10⁶

Construction Dates

Start of Project: 01/92

Start of RCC: 01/92

End of RCC: 08/93

End of Project: 12/93

Specifications

Height: 49 metres

Length: 609 metres

Volume of RCC: 200 m³x10³

Total volume: 225 m³x10³

Construction Methods

Facings

Upstream

Slope	Type
Vertical	RCC against formwork

Downstream

Slope	Type
0.122	RCC against formwork [stepped face]
0.75	RCC against formwork [stepped face]

Spillway

Slope	Type
0.75	RCC against formwork [stepped face]

Placement

Layers (mm)	Lifts (mm)
300	300

Cementitious material

Cement (kg/m³)
70

Pozzolan (kg/m³)	Pozzolan Type
130	Low-lime flyash (ASTM Class F)

Fundão

Full Dam Information

Details

Country: Brazil

Owner: ELEJOR - Centrais Elétricas do Rio Jordão

Type: Gravity

Purpose(s): Hydropower

River: Jordao

Reservoir capacity: 34 m³x10⁶

Construction Dates

Start of Project: -/04

Start of RCC: -/04

End of RCC: -/06

End of Project: -/07

Specifications

Height: 43 metres

Length: 445 metres

Volume of RCC: 200 m³x10³

Total volume: 220 m³x10³

Construction Methods

Facings

Upstream

Slope	Type

Downstream

Slope	Type

Spillway

Slope	Type

Placement

Layers (mm)	Lifts (mm)
300	300

Cementitious material

Cement (kg/m³)
64

Pozzolan (kg/m³)	Pozzolan Type
16	Natural pozzolan (ASTM Class N)

Castro Alves

Full Dam Information

Details

Country: Brazil

Owner: CERAM (Companhia Energética Rio das Antas)

Type: Gravity

Purpose(s): Hydropower

River: Das Antas

Reservoir capacity: 127 m³x10⁶

Construction Dates

Start of Project: -/05

Start of RCC: -/05

End of RCC: -/07

End of Project: -/08

Specifications

Height: 48 metres

Length: -

Volume of RCC: 200 m³x10³

Total volume: -

Construction Methods

Facings

Upstream

Slope	Type

Downstream

Slope	Type

Spillway

Slope	Type

Placement

Layers (mm)	Lifts (mm)

Cementitious material

Cement (kg/m³)
60

Pozzolan (kg/m³)	Pozzolan Type
15	Natural pozzolan (ASTM Class N)

Vaca

Full Dam Information

Details

Country: Belize

Owner: Belize Electric Company Ltd (BECOL) and A. Fortis Company, Canada

Type: Gravity

Purpose(s): Hydropower

River: Marcal

Reservoir capacity: 12 m³x10⁶

Construction Dates

Start of Project: 02/07

Start of RCC: 02/07

End of RCC: 10/09

End of Project: 12/11

Specifications

Height: 70 metres

Length: 245 metres

Volume of RCC: 200 m³x10³

Total volume: 220 m³x10³

Construction Methods

Facings

Upstream

Slope	Type
0.20	Traditional concrete against formwork

Downstream

Slope	Type
0.75	RCC against formwork (GEVR/GE-RCC) [stepped face]

Spillway

Slope	Type
0.75	Reinforced conventional concrete cast after RCC placement

Placement

Layers (mm)	Lifts (mm)
300	3600

Cementitious material

Cement (kg/m³)
94

Pozzolan (kg/m³)	Pozzolan Type
31	Low-lime flyash (ASTM Class F)

Batu Hampar

Full Dam Information

Details

Country: Malaysia

Owner: Jabatan Bekalan Air Negeri Sembilan

Type: Gravity

Purpose(s): Water Supply

River: Batu Hampar

Reservoir capacity: 3 m³x10⁶

Construction Dates

Start of Project: 11/07

Start of RCC: 11/07

End of RCC: 04/10

End of Project: 05/10

Specifications

Height: 75 metres

Length: 236 metres

Volume of RCC: 200 m³x10³

Total volume: 203 m³x10³

Construction Methods

Facings

Upstream

Slope	Type
	RCC against formwork (GEVR/GE-RCC)

Downstream

Slope	Type
	RCC against precast concrete blocks

Spillway

Slope	Type
	RCC against precast concrete blocks

Placement

Layers (mm)	Lifts (mm)
300	300

Cementitious material

Cement (kg/m³)
65

Pozzolan (kg/m³)	Pozzolan Type
120	Low-lime flyash (ASTM Class F)

Boqaata

Full Dam Information

Details

Country: Lebanon

Owner: Ministry of Energy and Water

Type: Gravity

Purpose(s): Water Supply

River: -

Reservoir capacity: 6 m³x10⁶

Construction Dates

Start of Project: 07/12

Start of RCC: 07/12

End of RCC: 12/16

End of Project: -/17

Specifications

Height: 72 metres

Length: 222 metres

Volume of RCC: 200 m³x10³

Total volume: 255 m³x10³

Construction Methods

Facings

Upstream

Slope	Type
Vertical	Reinforced conventional concrete cast after RCC placement
0.80

Downstream

Slope	Type
0.80	RCC against formwork (GEVR/GE-RCC) [stepped face]

Spillway

Slope	Type
0.80	RCC against formwork (GEVR/GE-RCC) [stepped face]

Placement

Layers (mm)	Lifts (mm)
300	300

Cementitious material

Cement (kg/m³)
90

Pozzolan (kg/m³)	Pozzolan Type
0	No pozzolan used -
