Gelantan

Download PDF data sheet
Gelantan completed
Gelantan completed

Particulars

Owner: Datang International Hydropower Generation Co. Ltd.

Designer: Tianjin Investigation & Design Institute

Contractor: Fujian (Minjiang) Construction Bureau

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 409 m3x106

Height: 113 metres

Length: 466 metres

Volume of RCC: 903 m3x103

Total volume: 1200 m3x103

Construction Dates

Start of Project: 01/03 (January 2003)

Start of RCC: 09/06 (September 2006)

End of RCC: 08/08 (August 2008)

End of Project: /09 ( 2009)

Country: China

River: Lixian

DMS Co-ordinates: 22˚42'9.16"N, 102˚03'25.33"E

DD Co-ordinates: 22.702543, 102.057037

Facings

Upstream

SlopeType
VerticalRCC against formwork (GEVR/GE-RCC)
0.20

Downstream

SlopeType
0.75RCC against formwork (GEVR/GE-RCC)

Spillway

SlopeType
0.75Traditional concrete against formwork

Placement

Layers (mm)Lifts (mm)


Cementitious material

Cement (kg/m3)
77
93
Pozzolan (kg/m3)Pozzolan Type
77Ground-granulated blast-furnace slag
93
