Ntimbale

Download PDF data sheet
Ntimbale completed
Ntimbale completed

Particulars

Owner: Department of Water Affairs

Designer: Knight Piesold

Contractor: WBHC

Statistics

Type: Gravity

Purpose(s): Water Supply

Reservoir capacity: 26 m3x106

Height: 33 metres

Length: 153 metres

Volume of RCC: 30 m3x103

Total volume: unknown

Construction Dates

Start of Project: 11/04 (November 2004)

Start of RCC: 04/06 (April 2006)

End of RCC: 09/06 (September 2006)

End of Project: 05/07 (May 2007)

Country: Botswana

River: unknown

DMS Co-ordinates: 20˚52'6.70"S, 27˚27'2.42"E

DD Co-ordinates: -20.868528, 27.450672

Facings

Upstream

SlopeType


Downstream

SlopeType


Spillway

SlopeType


Placement

Layers (mm)Lifts (mm)


Cementitious material

Cement (kg/m3)

Pozzolan (kg/m3)Pozzolan Type
