São Roque

Download PDF data sheet
Photo coming soon

Particulars

Owner: São Roque Energética S.A.

Designer: Engevix Construções S/A

Contractor: Engevix Construções S/A

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: unknown

Height: 68 metres

Length: 151 metres

Volume of RCC: 100 m3x103

Total volume: 583 m3x103

Construction Dates

Start of Project: /12 ( 2012)

Start of RCC: /17 ( 2017)

End of RCC: /18 ( 2018)

End of Project: /19 ( 2019)

Country: Brazil

River: Canoas

DMS Co-ordinates: 27˚35'50"S, 51˚28'37"W

DD Co-ordinates: -27.597221, -51.476944

Facings

Upstream

SlopeType
Vertical

Downstream

SlopeType
0.75

Spillway

SlopeType
0.75   [stepped face]

Placement

Layers (mm)Lifts (mm)


Cementitious material

Cement (kg/m3)

Pozzolan (kg/m3)Pozzolan Type
