Shuikou

Download PDF data sheet
Shuikou completed
Shuikou completed

Particulars

Owner: Shuikou Hydropower Plant

Designer: East China Hydroelectric Power Investigation & Design Institute of MOE & MWR

Contractor: Fujian Huatian Construction J.V.

Statistics

Type: Gravity

Purpose(s): Flood Control / Hydropower / Irrigation

Reservoir capacity: 2340 m3x106

Height: 101 metres

Length: 791 metres

Volume of RCC: 600 m3x103

Total volume: 1710 m3x103

Construction Dates

Start of Project: 03/87 (March 1987)

Start of RCC: 10/90 (October 1990)

End of RCC: 05/92 (May 1992)

End of Project: 05/95 (May 1995)

Country: China

River: Minjiang

DMS Co-ordinates: 26˚18'8.11"N, 118˚48'41.08"E

DD Co-ordinates: 26.302254, 118.811409

Facings

Upstream

SlopeType
VerticalTraditional concrete against formwork

Downstream

SlopeType
0.73Traditional concrete against formwork

Spillway

SlopeType
ogeeTraditional concrete against formwork

Placement

Layers (mm)Lifts (mm)
200  -200  -
330330

Cementitious material

Cement (kg/m3)
60
70
Pozzolan (kg/m3)Pozzolan Type
110Low-lime flyash (ASTM Class F)
90
