Asagi (Lower) Kaleköy

Download PDF data sheet
Photo coming soon

Particulars

Owner: Kalehan Energy Üretim ve Ticaret A.S.

Designer: unknown

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 432 m3x106

Height: 103 metres

Length: 346 metres

Volume of RCC: 1192 m3x103

Total volume: 1342 m3x103

Construction Dates

Start of Project: 03/13 (March 2013)

Start of RCC: /15 ( 2015)

End of RCC: /17 ( 2017)

End of Project: 04/18 (April 2018)

Country: Turkey

River: Murat

DMS Co-ordinates: 38˚49'51"N, 40˚42'35"E

DD Co-ordinates: 38.830833, 40.709721

Facings

Upstream

SlopeType
0.25RCC against precast concrete panels

Downstream

SlopeType
0.80Traditional concrete against formwork

Spillway

SlopeType


Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
130
Pozzolan (kg/m3)Pozzolan Type
0Milled sand
