Devecikonagi

Download PDF data sheet
Devecikonagi completed
Devecikonagi completed

Particulars

Owner: MCK Elektrik Uretim A.S.

Designer: unknown

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): Hydropower / Irrigation

Reservoir capacity: 6 m3x106

Height: 29 metres

Length: 313 metres

Volume of RCC: 54 m3x103

Total volume: 150 m3x103

Construction Dates

Start of Project: 05/10 (May 2010)

Start of RCC: 03/11 (March 2011)

End of RCC: 09/12 (September 2012)

End of Project: 01/13 (January 2013)

Country: Turkey

River: Emet

DMS Co-ordinates: 39˚52'31.86"N, 28˚34'31.6"E

DD Co-ordinates: 39.875519, 28.575443

Facings

Upstream

SlopeType
0.10Traditional concrete against formwork with external geomembrane

Downstream

SlopeType
0.75RCC against formwork

Spillway

SlopeType
0.80Reinforced conventional concrete cast after RCC placement

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
80
Pozzolan (kg/m3)Pozzolan Type
40Low-lime flyash (ASTM Class F)
