Dinh Binh

Download PDF data sheet
Dinh Binh completed
Dinh Binh completed

Particulars

Owner: Ministry of Agriculture and Rural Development (MARD)

Designer: Vietnam Hydraulic Consultant Company Nº1

Contractor: Engineering Construction Corporation Nº47

Statistics

Type: Gravity

Purpose(s): Flood Control / Hydropower / Irrigation / Water Supply

Reservoir capacity: 226 m3x106

Height: 55 metres

Length: 571 metres

Volume of RCC: 183 m3x103

Total volume: 430 m3x103

Construction Dates

Start of Project: 05/02 (May 2002)

Start of RCC: 08/05 (August 2005)

End of RCC: 12/07 (December 2007)

End of Project: 12/08 (December 2008)

Country: Vietnam

River: Kon

DMS Co-ordinates: 14˚9'23.86"N, 108˚46'21.47"E

DD Co-ordinates: 14.156628, 108.772629

Facings

Upstream

SlopeType
VerticalReinforced conventional concrete cast before RCC placement

Downstream

SlopeType
0.75RCC against formwork (GEVR/GE-RCC)

Spillway

SlopeType
ogeeReinforced conventional concrete cast after RCC placement

Placement

Layers (mm)Lifts (mm)
300900

Cementitious material

Cement (kg/m3)
70
126
Pozzolan (kg/m3)Pozzolan Type
175Low-lime flyash (ASTM Class F)
141
