Köprü

Download PDF data sheet
Köprü completed
Köprü completed

Particulars

Owner: Enerjisa En. Ut. A.S.

Designer: unknown

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 47 m3x106

Height: 103 metres

Length: 413 metres

Volume of RCC: 880 m3x103

Total volume: 1050 m3x103

Construction Dates

Start of Project: 07/09 (July 2009)

Start of RCC: 12/10 (December 2010)

End of RCC: 04/12 (April 2012)

End of Project: /12 ( 2012)

Country: Turkey

River: Göksu

DMS Co-ordinates: 37˚37'17.04"N, 35˚36'44.12"E

DD Co-ordinates: 37.621399, 35.612255

Facings

Upstream

SlopeType
VerticalTraditional concrete against formwork
0.60

Downstream

SlopeType
0.80Traditional concrete against formwork

Spillway

SlopeType
0.80Reinforced conventional concrete cast after RCC placement

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
85
Pozzolan (kg/m3)Pozzolan Type
45Low-lime flyash (ASTM Class F)
