Musatepe

Download PDF data sheet
Photo coming soon

Particulars

Owner: DSI - State Hydraulic Works

Designer: unknown

Contractor: unknown

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 13 m3x106

Height: 66 metres

Length: 165 metres

Volume of RCC: 130 m3x103

Total volume: 138 m3x103

Construction Dates

Start of Project: 09/08 (September 2008)

Start of RCC: /13 ( 2013)

End of RCC: /14 ( 2014)

End of Project: /15 ( 2015)

Country: Turkey

River: Robozik

DMS Co-ordinates: 37˚22'55"N, 42˚54'22"E

DD Co-ordinates: 37.381943, 42.906113

Facings

Upstream

SlopeType
0.10RCC against formwork

Downstream

SlopeType
0.80RCC against formwork

Spillway

SlopeType
0.80Reinforced conventional concrete cast after RCC placement

Placement

Layers (mm)Lifts (mm)
3001200

Cementitious material

Cement (kg/m3)
95
Pozzolan (kg/m3)Pozzolan Type
0No pozzolan used  -
