Pleikrong

Download PDF data sheet
Pleikrong completed
Pleikrong completed

Particulars

Owner: EVN (Electrictie de Vietnam)

Designer: PECC1 (Power Engineering Consulting Company Nº1)

Contractor: Song Da Corporation (SDC) and Water Resources

Statistics

Type: Gravity

Purpose(s): Hydropower

Reservoir capacity: 1048 m3x106

Height: 71 metres

Length: 495 metres

Volume of RCC: 326 m3x103

Total volume: 450 m3x103

Construction Dates

Start of Project: 11/05 (November 2005)

Start of RCC: 02/05 (February 2005)

End of RCC: 12/06 (December 2006)

End of Project: /07 ( 2007)

Country: Vietnam

River: Po Ko

DMS Co-ordinates: 14˚24'30.22"N, 107˚51'46.55"E

DD Co-ordinates: 14.408394, 107.862930

Facings

Upstream

SlopeType
VerticalTraditional concrete against formwork

Downstream

SlopeType
0.80Traditional concrete against formwork

Spillway

SlopeType
0.80Traditional concrete against formwork

Placement

Layers (mm)Lifts (mm)
300300

Cementitious material

Cement (kg/m3)
80
Pozzolan (kg/m3)Pozzolan Type
210Natural pozzolan (ASTM Class N)
